| CAMERA | |
| Image Sensor | 1/2.7″ Progressive Scan CMOS (0.370) |
| Maximum Resolution | 2592 (H) × 1944 (V) |
| Signal System | PAL/NTSC |
| Min. Illumination | Color: 0.001Lux@F1.4, B/W: 0Lux with IR on |
| Shutter Speed | Auto/Manual 1s ~ 1/100000s |
| Day/Night | Dual IR Cut Filter with Auto Switch |
| S/N Ratio | >60dB |
| Angle Adjustment | Pan 0 ~ 360°, Tilt 0 ~ 75°, Rotation 0 ~ 360° |
| LENS | |
| Lens Type | Motorised Auto-focus |
| Focal Length | 2.7 ~ 13.5mm |
| Lens Mount | Φ14 |
| Optical Zoom | 5x Optical Motorised Zoom |
| Digital Zoom | 16x Digital Zoom |
| Field of View | Horizontal: 96.7°~28.3°, Vertical: 70.8°~21.5°, Diagonal: 119.6°~36.1° |
| Aperture | F1.4 |
| Iris Type | Fixed Iris |
| VIDEO | |
| Video Compression | H.265+, H.265, H.264H, H.264M, H.264B, MJPEG |
| Streaming Capability | Dual Streams Individually configurable |
| Main Stream | PAL: 20fps (2592×1944, 25fps@2592×1520, 2560×1440, 2304×1296, 1920×1080, 720p NTSC: 20fps (2592×1944, 24fps@2592×1520, 2560×1440, 30fps@1296p, 1080p, 720p |
| Sub Stream | PAL: 25fps (704×576, 704×288, 352×288, 640×360) NTSC: 30fps (704×480, 704×240, 352×240, 640×360) |
| Third Stream | N/A |
| Video Bit Rate | 32Kbps~8Mbps (CBR/VBR Adjustable) |
| IMAGE | |
| Wide Dynamic Range (WDR) | 120dB |
| Back Light Compensation (BLC) | Supported |
| High Light Compensation (HLC) | Supported |
| Picture Overlay | N/A |
| Auto Exposure | Auto Level Control |
| Image Setting | Saturation, Brightness, Contrast, Sharpness, Image Rotation |
| Image Enhancement Function | AWB, AGC |
| Noise Reduction | 3D DNR |
| Smart Defog | Supported |
| Privacy Masking | Supported (4 Regions) |
| ROI | Supported (8 Regions) |
| EIS | N/A |
| AUDIO | |
| Audio Compression | G.711A/G.711U/ADPCM_D |
| Audio Streaming | Two-Way Audio |
| Audio Input | 1 Channel |
| Audio Output | 1 Channel |
| Built-in-Mic | Supported |
| Built-in Speaker | N/A |
| SMART EVENTS | |
| Event Trigger | Motion Detection, Mask Alarm, IP Address Conflict, Disk Full, Disk R/W Error, Event Input, Event Output |
|
Tripwire, Perimeter-Intrusion, Enter, Leave |
|
| LOCAL STORAGE | |
| Memory Card Slot | Built-in Micro SD card slot, up to 512GB |
| ANR | Supported (Only Support with AVAIVI ANR Enabled NVR) |
| ALARM INTERFACE | |
| Alarm Input | 1 Channel |
| Alarm Output | 1 Channel |
| NETWORK | |
| Ethernet | 1 x RJ45 10M/100M Self Adaptive Ethernet Port |
| IP Support | Static, Dynamic |
| HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, DHCP, DNS, DDNS, NTP, QoS, IPv4, SSH, Unicast, RTSP, FTP, P2P. | |
| IP Address Filtering | Supported |
| Multi Level User ID/ Password | Supported |
| SIP/VoIP | N/A |
| Web Viewer | IE, Chrome, Firefox, Safari |
| Management Software | AVAIVI-CMS |
| Mobile Application | VideoSight |
| P2P Cloud | Supported |
| System Compatibility | Onvif Profile G, M, S, T |
| User/Host | 5 |
| ILLUMINATOR | |
| IR LEDs | 4 |
| IR Distance | Up to 80m 262.46 ft.) |
| Wavelength | 850nm |
| White/Warm light LEDs | N/A |
| ENVIRONMENTAL | |
| Power Supply | PoE (802.3af), DC 12V±25% |
| Power Consumption | 8.5W Max-PoE, 7.5W Max-12V (With IR on) |
| Operating Temperature | -40°C~60°C, Less than 95% RH |
| Ingress Protection | IP67 |
| Vandal Resistance | IK10 |
| Heater | N/A |
| Casing | Metal |
| Dimensions | 239 x 90 x 90mm |
| Weight | 1280g |
